| TECHNICAL DATA | ||
| Part No SBR | 5010210051221 | |
| Product Code | SD-050-0140-020-D25.4-E20-0.55KW-3N400-C2-B0 | |
| Output Torque | Nm | 140 |
| Output Speed | rpm | 20 |
| Output Shaft | mm | 25,4 |
| Motor Power | kW | 0,55 |
| Operating Voltage | V | 3N~400 |
| Operating Frequency | Hz | 50 |
| Operating Current | A | 3,9/2,3 |
| Limit Switch Range | rpm | -20 |
| Duty Types | ED | IP54 |
| IP Protection Class | IP | +40(60) |
| Max Operating Temperature | °C | < 70 |
| Working Noise Level | dB(A) | 50 |
| Door Weight | kg | 20 |
| Weight | kg | SD |
